Discovery 3 Eight-Inch Tablet Holder

ABS · PETGMULTI-PART11 FILESGPLInterior

Loading 3D viewer...

CARGO ID · LR-3D / 0064QTY 11 · STLHANDLE · NO SUPPORTS

Field photographs5 PLATES

PLATE 01 / 05No caption recorded

Cargo manifestMAN-0064

[01]191002_D3_tab_holder_A.stl191002_D3_tab_holder_A.stl.STL
[02]191002_D3_tab_holder_Assembly.stl191002_D3_tab_holder_Assembly.stl.STL
[03]191002_D3_tab_holder_B_-_Body1.stl191002_D3_tab_holder_B_-_Body1.stl.STL
[04]191002_D3_tab_holder_B_-_Body2.stl191002_D3_tab_holder_B_-_Body2.stl.STL
[05]191002_D3_tab_holder_B_-_Insert.stl191002_D3_tab_holder_B_-_Insert.stl.STL
[06]191002_D3_tab_holder_B_-_Spring.stl191002_D3_tab_holder_B_-_Spring.stl.STL
[07]191002_D3_tab_holder_Cable_man.stl191002_D3_tab_holder_Cable_man.stl.STL
[08]191002_D3_tab_holder_ball_head_-_Part_1.stl191002_D3_tab_holder_ball_head_-_Part_1.stl.STL
[09]191002_D3_tab_holder_ball_head_-_Part_2.stl191002_D3_tab_holder_ball_head_-_Part_2.stl.STL
[10]191002_D3_tab_holder_ball_head_cover.stl191002_D3_tab_holder_ball_head_cover.stl.STL
[11]191002_D3_tab_holder_nut.stl191002_D3_tab_holder_nut.stl.STL
[12]Bounding box361.955 × 215.600 × 119.189 mm
[13]Volume449,164.398 mm³

Depot briefBY JAN ERBEN (HYTA)

Multi-part eight-inch tablet holder designed for the Discovery 3 cabin. Includes the mount, articulated ball-head components, spring, insert, cable guide, nut, and assembly model.
