Webasto MultiControl Ashtray Mount
ABS · PETGMULTI-PART4 FILESGPLDashboard
Loading 3D viewer...
CARGO ID · LR-3D / 0072QTY 4 · STLHANDLE · NO SUPPORTS
Field photographs6 PLATES
PLATE 01 / 06No caption recorded
Cargo manifestMAN-0072
- [01]210218_WMH_Base.stl210218_WMH_Base.stl.STL
- [02]210218_WMH_Bracket.stl210218_WMH_Bracket.stl.STL
- [03]210218_WMH_Front_Panel.stl210218_WMH_Front_Panel.stl.STL
- [04]210218_WMH_Spring_Clip.stl210218_WMH_Spring_Clip.stl.STL
- [05]Bounding box126.833 × 84.000 × 73.400 mm
- [06]Volume58,467.809 mm³
Depot briefBY JAN ERBEN (HYTA)
Four-part holder for installing a Webasto MultiControl unit in place of the factory ashtray, including base, bracket, front panel, and spring clip.
